Security System | Transmission Distance | Suggested Cable |
DVR | Length≦200M | RG59(Or Similar Types) |
200M<Length≦500M | RG6(Or Similar Types) | |
Length>500M | RG11(Or Similar Types) | |
Length≦100M | Cat5e or Twisted Cable | |
Length>1000M | Optical fiber Cable | |
NVR | Length≦100M | UTP CAT5E CCA |
UTP CAT5E 0.45mm BC | ||
100M<Length≦200M | UTP CAT5E BC | |
200M<Length≦300M | UTP CAT6 BC | |
Length>1000M | Optical fiber Cable | |
Power &Control | Transmission Distance | Suggested Cable |
PTZ Control | Length≦100M | RVV6×0.5mm2 |
Length>100M | RVV6×0.75mm2 | |
Lens Control | RVV4×0.5mm2 | |
Decoder Control | RVV2×1mm2 Shielded | |
Camera Power (20PCS Camera) | 34-50M | 6mm2 Power Cable |
21-33M | 4mm2 Power Cable | |
20M | 2.5mm2 Power Cable |
